Page #96 background imageLoading...
Page #96 background image






0&386%
Figure 7-2 Mounting panel cutout
Dimension drawing
WARNING
Danger to life from hazardous voltage
It is possible to reach into installation holes for control devices (shown in gray in the drawing).
Make sure that no live parts can be touched behind the holes within a clearance of at least
85 mm (hatched area in the drawing).
85





85
Figure 7-3 Dimensions and clearances
Anschließbare Komponenten
7.1 MCP 483 USB
PPU and components
96 Manual, 05/2015, 6FC5397-2DP40-3BA4
