Siemens SINUMERIK 828D Manual

The machine control panel has two override switches for the feedrate and for the spindle. The
switch positions with the associated values are listed in the following tables:
● You can read out the value for the feedrate override in the input image DB1000.DBB3.0...4.
Position Value
0 % 0x01
2 % 0x02
4 % 0x06
6 % 0x07
10 % 0x04
20 % 0x0C
30 % 0x0D
40 % 0x0F
50 % 0x0E
60 % 0x0A
70 % 0x0B
80 % 0x08
90 % 0x19
100 % 0x1A
105 % 0x1E
110 % 0x1F
120 % 0x1C
● You can read out the value for the spindle override in the input image DB1000.DBB0.4...7.
Position Value
50 % 0x10
55 % 0x30
60 % 0x20
65 % 0x60
70 % 0x70
75 % 0x50
80 % 0x40
85 % 0xC0
90 % 0xD0
95 % 0xF0
100 % 0xE0
105 % 0xA0
110 % 0xB0
115 % 0x90
120 % 0x80
Anschließbare Komponenten
7.1 MCP 483 USB
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 99

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
