Appendix
B-2
B.1 Settings
Addr. Setting Title Function Setting Options Default Setting Comments
103 Grp Chge OPTION Scope of Functions Disabled
Enabled
Disabled Setting Group Change Option
110 Trip mode Scope of Functions 3pole only
1-/3pole
3pole only Trip mode
114 Dis. PICKUP Scope of Functions Z< (quadrilat.)
I> (overcurr.)
U/I
U/I/<phi>
Disabled
I> (overcurr.) Distance protection pickup
program
120 Power Swing Scope of Functions Disabled
Enabled
Disabled Power Swing detection
121 Teleprot. Dist. Scope of Functions PUTT (Z1B)
PUTT (Pickup)
POTT
Dir.Comp.Pickup
UNBLOCKING
BLOCKING
Rev. Interlock
Pilot wire comp
Disabled
Disabled Teleprotection for Distance prot.
122 DTT Direct Trip Scope of Functions Disabled
Enabled
Disabled DTT Direct Transfer Trip
124 SOTF Overcurr. Scope of Functions Disabled
Enabled
Disabled Instantaneous HighSpeed SOTF Over-
current
125 Weak Infeed Scope of Functions Disabled
Enabled
Disabled Weak Infeed (Trip and/or Echo)
126 Back-Up O/C Scope of Functions Disabled
TOC IEC
TOC ANSI
TOC IEC Backup overcurrent
130 Sens. Earth Flt Scope of Functions Disabled
Enabled
Disabled Sensitive Earth Flt.(comp/ isol. starp.)
131 Earth Fault O/C Scope of Functions Disabled
TOC IEC
TOC ANSI
TOC Logarithm.
Definite Time
U0 inverse
Disabled Earth fault overcurrent
132 Teleprot. E/F Scope of Functions Dir.Comp.Pickup
UNBLOCKING
BLOCKING
Disabled
Disabled Teleprotection for Earth fault overcurr.
133 Auto Reclose Scope of Functions Disabled
1 AR-cycle
2 AR-cycles
3 AR-cycles
4 AR-cycles
5 AR-cycles
6 AR-cycles
7 AR-cycles
8 AR-cycles
ADT
Disabled Auto-Reclose Function
134 AR control mode Scope of Functions Pickup w/ Tact
Pickup w/o Tact
Trip w/ Tact
Trip w/o Tact
Pickup w/ Tact Auto-Reclose control mode
135 Synchro-Check Scope of Functions Disabled
Enabled
Disabled Synchronism and Voltage Check
137 Overvoltage Scope of Functions Disabled
Enabled
Disabled Overvoltage
Please see "
Note
" for settings right at the end of Section B.1.
