Chapter 5 Display and Setting of Various Functions
HRL Series 5.4 Description of the Screen
5-27
Table 5.4-5 TEMP READY signal setting
No.
Indication
Item
Setting and selection
Setting range
(1)
High/
Low
Upper/lower
temperature
limit
[High]
Sets the upper
temperature limit for
circulating fluid SP.
+0.1 ºC to +10.0 ºC
 +1.0 ºC
[Low]
Sets the lower
temperature limit for
circulating fluid SP.
-0.1 ºC to -10.0 ºC
 -1.0 ºC
(2)
Ready/
Out Time
Stable
temperature
time/out
time
[Ready Time]
“TEMP READY” signal
is output when the set time
has passed after the
circulating fluid temperature
rises/drops within the range
of (1) “Upper/Lower
temperature limit.”
10sec to 9999sec
 180sec
[Out Time]
“TEMP READYˮ is cleared
when the set time has
passed after the circulating
fluid temperature rises/drops
outside the range of (1)
“Upper/Lower temperature
limit” in the “TEMP READY”
condition.
0sec to 600sec
 5sec
(3)
Alarm
Type
AL12 alarm
operation

Disabled
－
Operation continues
during the alarm
－
Operation stops
during alarm
－
(4)
Start Time
Start time of
AL12 alarm
monitoring
[Start Time]
Monitoring of “AL12: TEMP
READY alarm” starts when
the set time has passed
after the start of operation.
0sec to 9999sec
 600sec
 By default.
■ About TEMP READY function
The operation chart of “TEMP READY” signal is shown in Fig. 4-2 TEMP READY signal
chart.
[Example of setting]
• (1) “High” Upper temperature limit: +2ºC and “Low” Lower temperature limit: -2ºC
• (2) “Ready Time” Stable temperature time: 300 sec and “Out Time” extra
temperature time: 200 sec
• (3) “Alarm Type” Alarm operation (AL12): “WRN”
• (4) “Start Time” Start time of alarm monitoring (AL12): 1000 sec
