Chapter 2 Name and Function of Parts
HRL Series 2.1 Model Number of Product
2-1
Chapter 2 Name and Function of Parts
2.1 Model Number of Product
The product can be ordered with the model number configured as shown
below.
The product needs to be handled in different ways, depending on the part
number. Refer to “1.4 Product Label" and check the part number of the
product.
Fig. 2-1 Product model number (Air-cooled type)
HRL
④Power supply
- -
A
40
40
3phase AC380-415V(50/60Hz)
3phase AC460-480V(60Hz)
①Cooling capacity
CH1
200 19 kw
100 9 kw
③Piping thread type
Nil Rc
F G (Rc-G thread adapter set is included)
N NPT (Rc-NPT thread adapter set is included)
②Cooling method
A Air-cooled refrigeration
300 26 kw
CH2
1 kw
1 kw
1 kw
-
⑤Option
Nil CH2 Electric conductivity control
D1 CH1,CH2 Electric conductivity control
T2 High-Pressure Pump
T3
*1
High-Pressure Pump
*1 Applicable only to HRL300-A -40.
