HRX-OM-X037
Chapter 2 Name and Function of Parts
2.1 Model Number of Product HRL Series
2-2
Fig. 2-2 Product model number (Water-cooled type)
HRL
④Power supply
- -
W
40
40
3phase AC380-415V(50/60Hz)
3phase AC460-480V(60Hz)
①Cooling capacity
CH1
200 21.5 kw
100 10 kw
③Piping thread type
Nil Rc
F G (Rc-G thread adapter set is included)
N NPT (Rc-NPT thread adapter set is included)
②Cooling method
W Water-cooled refrigeration
CH2
1 kw
1 kw
-
⑤Option
Nil CH2 Electric conductivity control
D1 CH1,CH2 Electric conductivity control
T2 High-Pressure Pump
