HRX-OM-X037
Chapter 3 Transport and Setting Up
HRL Series 3.3 Installation
3-29
Ethernet Modbus/TCP communication connector
The following connector is used for this product as Ethernet Modbus / TCP
communication connector. Please prepare suitable mating connector.
Table 3.3-9 Ethernet Modbus / TCP communication connector
Fig. 3-15 Ethernet Modbus/TCP communication wiring
Connector specification (this product side)
RJ45
RJ45
