■ Installation of the particle filter element
1. Remove the filter case using the maintenance handle.
Fig. 3-25 CH1 particle filter case removal
Fig. 3-26 CH2 particle filter case removal
Filter case
Maintenance handle white
( Accessory )
Filter case
Maintenance handle black
( Accessory )
