HRX-OM-X037
Chapter 3 Transport and Setting Up
HRL Series 3.3 Installation
3-37
9. Attach the CH2 filter bracket.
Fig. 3-24 CH2 side Installation of filter bracket.
Panel screw
(Recommended tightening
torque：3.0N・m)
Filter tapping screw
(Recommended
tightening torque：3.0 to 5.0N・m)
