Chapter 3 Transport and Setting Up
3.3 Installation HRL Series
3-40
Fig. 3-28 Connection to the drain port
Hold the ball valve.
Without using a wrench to hold the drain port’s ball valve, the ball
valve may rotate. This could cause fluid leakage and/or product
malfunction. Ensure that the ball valve of the drain port is held
securely.
