SMC Networks HRL100-A 40 Series User Manual

HRX-OM-X037
Chapter 3 Transport and Setting Up
HRL Series 3.3 Installation
3-41
■ How to connect to the facility water inlet/outlet
Fig. 3-29 Connection to the facility water inlet/outlet
When piping the facility water inlet/outlet,
hold the facility water port with a wrench not
to rotate it.
Hold the facility water inlet/outlet
If piping is performed without fixing the facility water inlet/outlet, it
may cause deformation of the panel. Ensure that the facility water
inlet/outlet is held securely.
