Snap-On TRITON-D10 User Manual

Scope Multimeter Overview
71
Figure 9-1
Risk of electrical shock.
• Do not exceed voltage limits between inputs as indicated on the rating label.
• Use extreme caution when working with circuits that have greater than 40
volts AC or 24 volts DC.
Electrical shock can cause personal injury, equipment damage, and/or circuit
damage.
IMPORTANT
If arrows are displayed in the live voltage values, discontinue circuit
testing.
Correct an out-of-range condition by selecting a scale setting appropriate for the
signal being sampled. See Scale (Vertical scale adjustment) on page 82 for more
information.
9.2 Overview
The Scope Multimeter test functions are:
• Digital Multimeter (DMM)
• Graphing Multimeter (GMM)
• Lab Scope
IMPORTANT
Over Voltage Installation Category (CAT) - This Scope Multimeter is rated
as a Category (CAT) 1 device. The maximum rated transient over voltage
impulse is 500 volts, DO NOT exceed the rated transient over voltage.
9.2.1 Digital Multimeter (DMM)
The digital multimeter gives you the ability to quickly make precise common
electrical measurements (e.g. DC and AC voltage, resistance and amperage) on
circuits and components to verify operation. The meter displays measurements in a
digital numerical format, and is typically used for measuring signals that are not
rapidly changing.
The DMM is ideal for performing basic tests on most standard automotive circuits,
and displays the results in a large easy to see format.
To use the DMM, select the Scope Multimeter icon from the home screen then
select Digital Multimeter from the menu. See Tests and Capabilities (Quick
Reference) on page 74 for a list of available testing functions.
Specifications
WARN ING
Function Range Accuracy/Comments
Signal
Measurement
Ch. 1— (yellow jack)
Input is referenced to common
ground (GND— (black jack)
VDC (Full Scale) 75VDC
Do not measure greater than
75VDC
VAC (Full Scale) 50VAC
Do not measure greater than
50VAC (rms)
Signal
Measurement
Input Impedance
10 MΩ -
Ohm Measurement
Diode Test
Continuity Test
Ch. 1— (yellow jack (–))
Ch. 2— (green jack (+))
-
Ohms 40 Ω—4 MΩ Fixed scales or auto ranging
Glitch Capture Approximately 50 µS -
Diode test 2V scale -

Snap-On TRITON-D10 Specifications

General

Processor	Octa-core 2.0 GHz
Memory	4 GB RAM
Connectivity	Wi-Fi, Bluetooth
Battery Life	Up to 8 hours
Operating System	Android
Software Updates	Automatic via Wi-Fi
Warranty	1-year warranty
Software	Snap-on Diagnostic Software
Diagnostic Capabilities	Live Data
