Scope Multimeter Test Leads and Accessories
77
9.4.7 Pressure Transducers and Adapters (optional)
Different pressure transducers and adapters are available for measuring positive
and negative gas and liquid pressures. Depending on the adapter, measurement
capabilities range from 1 to 5000 psi and up to 29 inHg. Measurement and
application capabilities vary per device.
Figure 9-8
9.4.8 Waveform Demonstration Tools (optional)
To help you sharpen your lab scope and graphing multimeter skills, optional
waveform demonstration tools are available as a training aid. These demonstration
tools generate common waveforms, and allow you to vary their display
characteristics by turning glitches on/off, helping you to become more familiar with
the lab scope controls. Common waveforms include, AC sine wave, variable
frequency and pulse, secondary ignition, and more. There are two tools currently
available, the standard model (Figure 9-9 left) and the vehicle simulator model
(Figure 9-9 right) which produces waveforms (e.g. Crankshaft Position Sensor
(CKP), Camshaft Position Sensor (CMP), Accelerator Pedal Sensor (APP), Wheel
Speed Sensor (WSS) Signals, and more) representative of a 2012 BMW 328i
Sedan.
Figure 9-9
