Sony MVS-8000X System User Manual

Chapter 20 Switcher Setup (Switcher)
1066
Interfacing With External Devices (Device Interface Menu)
3 Depending on the selection in step 3, use any of the following methods to
make the setting.
• Press directly on the list on the right of the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
4 Press [Set].
In the list on the right of the status area, the selected content is reflected in
the specified DME channel.
Repeat steps 3 to 6 as required.
Selecting the Mode for Turning Off Keys Upon
Receiving the Editor Command
Selects the mode for turning off keys when an “All Stop” command is received
from the editor.
1 In the Switcher >Device Interface menu, press [Editor I/F].
The Editor I/F menu appears.
2 Select one of the following modes.
All: When an “All Stop” command is received, all keys for the selected
regions are turned off.
Specified: When an “All Stop” command is received, among all the keys
for the selected regions, only the keys specified by the editor are
turned off.
Notes
When an “All Stop” command is received in the process of a transition, the
keys selected for the next transition are also turned off.
Knob Parameter Adjustment Setting values
2 Src No AUX bus number 0 to 48

Sony MVS-8000X System Specifications

General

Category	Video Production Switcher
Audio Inputs	Embedded audio support; Optional audio interface boards available
Audio Outputs	Embedded audio support; Optional audio interface boards available
Frame Rate Support	59.94i/50i, 23.98P, 24P, 25P, 29.97P
Video Format Support	1080i, 720p, 480i, 576i
Transition Effects	Mix, Wipe
Control Interface	Touchscreen
Compatibility	Compatible with various Sony equipment
Power Supply	100-240V AC, 50/60Hz
