Chapter 6 DME Wipes
285
DME Wipe Settings for Independent Key Transitions
1
In the <Pattern Select> group of the Key1 DME Wipe Adjust menu, press
[1ch] for one-channel mode or [2ch] for two-channel mode.
The Pattern Select menu appears.
2
Select the desired DME wipe pattern group with one of the following
buttons.
(In two-channel mode, only Page Turn and Page Roll are selectable.)
• Slide/Squeeze: slide and squeeze
• Split/Door: split and door
• Mirror/Sphere: mirror and sphere
• Character Trail: character trail
• Wave/Ripple: wave and ripple
• Page Turn/Roll: page turn and page roll
• Frame I/O: frame in/out
• 2D Trans/3D Trans: 2D Trans and 3D Trans
• Sparkle/Split Slide: sparkle and split slide
• User Program: user programmable DME
For details of DME wipe patterns, see “Types of DME Wipe Pattern”
(page 262) and “DME Wipe Pattern List” (page 418).
The patterns from the selected pattern group appear on the screen.
3
Press the button to select the desired pattern.
Setting Independent Key Transition DME Wipe
Modifiers
You can add modifiers such as pattern position and size for an independent key
transition DME wipe.
For introductory information, see “Setting the DME wipe position
(Positioner)” (page 278) and “Setting the DME wipe pattern size (Size)” (page
279).
Setting the DME wipe position (Positioner)
For applicable pattern numbers, see page 270.
1
In the <Position> group of the Key1 DME Wipe Adjust menu, press
[Position], turning it on.
2
Set the following parameters.
To Next Page
