Sony MVS-8000X System - Three-Dimensional Transformation Operations; Basic Operations

Chapter 11 DME Operations
481
Three-Dimensional Transformation Operations
Three-Dimensional Transformation
Operations
To carry out three-dimensional DME transformations, use either part of the
device control block (joystick) and numeric keypad control block or the
optional device control block (MKS-8031TB trackball module).
Basic Operations
Controls used for DME operations
Operating buttons
Joystick
Part of the numeric
keypad control block
MENU button
Part of the device control block (joystick)
Region selection buttons (DME1 to 4)
