Sony MVS-8000X System - Making an External Box Setting

Chapter 23 Setup Relating to Router Interface and Tally (Router/Tally)
1101
Router Interface Settings (Router Menu)
272 × 274: Assign to S-Bus space with the switcher input/output at
272×274 size.
136 × 138: Assign to S-Bus space with the switcher input/output at
136×138 size.
128 × 128: Assign to S-Bus space with the switcher input/output at
128×128 size.
3 Turn the knobs to set the parameters for the following items.
Source: Specify the start address of the matrix source.
Destination: Specify the start address of the matrix destination.
Level: Specify the level in the S-Bus space.
a) When the matrix size is Standard, the maximum value is 889. For the Compact size, the
maximum value is 897.
b) When the matrix size is Standard, the maximum value is 887. For the Compact size, the
maximum value is 897.
Making an External Box Setting
1 In the Router/Tally >Router menu, press [External Box Assign].
The External Box Assign menu appears.
The status area shows the external box size, address, and other settings.
2 In the <Device> group, select what the setting applies to (one of External
Box 1 to 4).
3 In the <Matrix Size> group, select the number of inputs.
No Assign: Do not use.
8×1: Select an external box with 8 inputs and 1 output.
16×1: Select an external box with 16 inputs and 1 output.
32×1: Select an external box with 32 inputs and 1 output.
4 Turn the knobs to make adjustments.
Knob Parameter Adjustment Setting values
1 Source Source start address
1 and upwards
a)
2 Destination Destination start address
1 and upwards
b)
3 Level Level 1 to 8
