Chapter 9 Color Corrector
386
Color Corrector Functions
8
In the <Spot CCR> group, press [Spot CCR] to display the parameters, and
adjust the replacement color.
.
To return the parameters to their default settings
In the <Spot CCR> group, press [Unity].
Masking a part of the spot color adjustment
Set [Mask] to On in the Spot CCR/Output menu, then carry out the same
procedure as in “Masking a part of the primary color correction” (page 378).
Adjusting the color outside the spot color adjustment region
1
In the Spot CCR/Output menu, press [Outer Out Proc] in the <Outer Out
Proc> group, turning it on.
2
Adjust the following parameters.
To return the parameters to their default settings
In the <Outer Out Proc> group, press [Unity].
Output Video Processing Operations
Carry out the following corrections are available on the YUV signal.
• Video signal overall gain adjustment
• Y signal gain adjustment
• Y signal offset adjustment
• C signal gain adjustment
• C signal hue adjustment
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
1 Video Gain Video signal gain –200.00 to +200.00
2 Y Gain Y signal gain –200.00 to +200.00
3 C Gain Chrominance signal gain –200.00 to +200.00
4 Hue Delay Hue delay –180.00 to +180.00
5 Black Level Black level –116.90 to +116.90
