Introduction
SPECIFICATIONS
Model FL19F Fixed Base Model FL19H Hydraulic Base
Safe Working Load 100 lb (45 kg) 100 lb (45 kg)
Overall Length & Width
• No Accessory Supports
• With Accessory Supports
65 1/2 in x 37 in (166 x 94 cm)
72 3/8 in x 37 1/2
in (184 x 95 cm)
65 1/2 in x 37 in (166 x 94 cm)
72 3/8 in x 37 1/2
in (184 x 95 cm)
Weight Capacity 400 lb (181 kg) 400 lb (181 kg)
Overall Weight (without options) 310 lb (140.6 kg) 375 lb (170 kg)
Height Range (to litter top)
• High
• Low
33 in (84 cm)
33 in (84 cm)
40 in (102 cm)
33 in (84 cm)
Litter Positioning
• Manual Fowler
• Pneumatic Fowler
• Trend./Reverse Trend.
• Foot Section
0°
/ 25° / 40°
/ 55°
0°
to 50°
N/A
0°
/ 6° / 12°
0°
/ 25° / 40°
/ 55°
0° to 50°
+/- 9.5°
0°
/ 6° / 12°
Patient Surface 29.5 in x 57 in (75 x 145 cm) 29.5 in x 57 in (75 x 145 cm)
Caster Diameter 5 in (13 cm) 6 in (15 cm)
Brake System Four Locking Casters Four Wheel Ring Brake System
Scale (Optional)
Capacity Patients weighing 4 lb (1.8 kg) to 100 lb (54.4 kg)
Accuracy
Perform scale measurement when unit is flat:
± 0.5 lb. (0.2 kg) at 50 lb. (22 kg) or less
± 1.0 lb. (0.4 kg) at ≥ 50 lb. (22 kg)
Power
System
Battery - 4 x “C” Type, Alkaline, 1.5VDC
Electrical
Rating
6 VDC, 0.15 A
Stryker provides special attention to product improvement and reserves the right to change specifications without
notice.
Compliant with the following standards: CSA C22.2, No. 60601.1; UL2601-1; IEC/EN 60601-1.
Note: The Cub
®
is CE Mark only without the scale option.
