www.stryker.com 1900-009-002 REV B 1-127
English
Protective Top with Support - FA64183-XXX
OL190089 ET OL190091
8*
VIEW WITH STANDARD ACCESSORY BRACKETS
A
39
12
6
16
6
5
18
16
29
7
6
36
44
42
1,34
44
2
37
6
43
37
1,34
38
2
41
42
6
37,34
33
35
40
40
32
15
27
4
5
29
6
7
24
45
B
B
A
20
4
17
29
19
37,34
37
43
44
23
22
38
6
42
1,34
37
1,34
41
45
6
44
3
12
6
14
11
9
29
10
39
13
* PART 8 AND 12 MUST BE ASSEMBLY IN
THE MEMBRANE PROTECTIVE TOP (3)
BEFORE YOU BEGIN ASSEMBLY.
T25
T25
T15
T75
T25
T75
T15
T15
T15
T15
T15
T15
T25
T25
T15
T15
T25
T25
T25
22 19-0527 Ground Chain 4
23 VR11H42 Pop Rivet 4
24 VG50A0632 Hitch Pin 4
27 QE71-1339-XXX Manufacturer Label 1
29 QE71-0533 Protective Top Label 4
32 19-0795Z Friction Plate 4
33 QDF9540 Fiber Washer 8
34 M0008 Thread Locker (Medium) .32mL
35 VEX3A1N Hex Nut Insert 2
36 VW10C081802 Nylon Washer 2
37 VV33A1N24 Pan Head Machine Screw 6
38 VE30A1N Nylon Hex Locknut 12
39 QE71-0560-XXX Warning Label 2
40 VV33A1N52 Pan Head Machine Screw 8
41 90-1440P Protective Top Support 2
42 90-1441C Locking Bushing 4
43 QE71-0780-XXX Move CUB Label 2
44 VV83A9G16 Pan Head Tapping Screw 4
45 90-1480P Support Reinforcement Rail 2
1 VE40A1N Cap Nut 12
2 19-0723 Outer Support 12
3 QDF19-0725 Protective Top Membrane 1
4 90-1487Z Protective Top Bolt 4
5 19-0820 Protective Top Guide 4
6 VVZ7A1E32 Pan Head Tapping Screw 28
7 VV33A1N50 Pan Head Machine Screw 4
8 19-0677P Protective Top Upper Rail 2
9 QP19-0545 Release Knob, Outer 4
10 QE71-0498 Release Knob Label, Orange 4
11 QP19-0546 Release Knob, Inner 4
12 19-0676P Protective Top Lower Rail 2
13 QRC19-0839 Protective Top Spring 2
14 19-0680P Upper Hinge Arm 4
15 VW30A0816 Spring Washer 8
16 19-0724 Inner Support 8
17 90-1494P Lower Hinge Arm 4
18 QP19-0986-05 Mounting Structure 2
19 QDF5092 Snap Button 4
20 19-0684P Protective Top Post, Left 4
Item Part No. Part Name Qty.Item Part No. Part Name Qty.
L64-109-XXX Rev F (Reference only)
