Stryker CUB FL19F User Manual

Return To Table of Contents
1-96 1900-009-002 REV B www.stryker.com
English
Standard Accessory Brackets with Scale Option
OL190186W Rev E (Reference only)
T130 14
13
T75 12
8
6
T175
30
25
18
14 T130
13
11
A
A
B
B
C
C
D
D
E
E
15
16
19
21
22 T7
T7 22
24 T35
26
27
28
29
24 T35
1
14 T130
13
T75 12
11
10
4
1
6
5
3
2
7
T175
8
9
13
T130 14
31
5
3
FOOT LEFT
HEAD LEFT
HEAD RIGHT
FOOT RIGHT
23
T35
24
10
17
20
CONNECT TO THE PC BOARD
THE BUMPER (ITEM #5) MUST SPIN FREELY
AFTER BOLT (ITEM #6/#31 AND #3) IS TIGHTENE
D.
32
32
1 VB15A1N24 Hex Bolt 4
2 19-0973C Fixed Socket Std. Bracket 1
3 VE30A1P Nylon Locknut 3
4 19-0833P Standard Support, Left 1
5 QDF5072 Corner Bumper 3
6 VB15A1P40 Hex Bolt 2
7 VB15A1P24 Hex Bolt 1
8 VW20A12 Nylon Hex Locknut 2
9 VW11A12 Nylon Hex Locknut 1
10 VB35A1O24 Carriage Bolt 4
11 VW10A08 Washer 4
12 VE30A1N Nylon Hex Locknut 4
13 VW10A10 Washer 4
14 VE30A1O Nylon Hex Locknut 4
15 QE71-0654-F Electronic Component Label 1
16 QP19-0868 Bracket Cover w/ Scale 1
17 QE18545 ‘Refer to Manual’ Label 1
18 19-0777C Fixed Socket 1
19 QDF19-0867 Scale Membrane 1
20 QE71-0680-F ‘Weighing Zone’ Label 1
21 QDF19-0888 Scale PC Board 1
BOTTOM VIEW OF CONTROL BOARD
Power Supply Connector
Angle Sensor Cable
Foot Left
Foot Right
Head Left
Head Right
Item Part No. Part Name Qty.
22 VV83A9E08 Pan Head Tapping Screw 5
23 QDF9518 Black Cable Tie 2
24 VV81A9E16 Flat Head Tapping Screw 7
25 19-0879P Standard Bracket for Scale 1
26 QDF19-0933 Battery to PC Board Lead 1
27 QDF7909 ‘C’ Type Battery 4
28 QE71-0656-F ‘Battery Type’ Label 1
29 QP19-0887 Battery Housing Cover 1
30 19-0778Z Fixed Socket Spacer 1
31 VB15A1P50 Hex Bolt 2
32 VW11A9E Flat Washer 2
Item Part No. Part Name Qty.
Standard Accessory Brackets with Scale - OL190186W Rev E - (Reference only)
