AC-17
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)
General Description
• RHD MODEL
(1) Condenser (5) Compressor Tightening torque: N·m (kgf-m, ft-lb)
(2) High-pressure hose (6) O-ring T1: 7.4 (0.75, 5.4)
(3) Low-pressure hose (7) Triple pressure switch T2: 15 (1.5, 10.8)
(4) Pipe
AC-00243
(1)
(3)
(4)
(7)
(5)
(2)
T1
T1
T2
(6)
(6)
(6)
(6)
(6)
T2
