Subaru Forester 2004 - Page 387

SE-7
SEAT
Front Seat
3) Loosen the screw, and then remove the hinge
cover.
4) Remove two reclining hinge securing bolts on
each side.
5) Remove the cover (A), and then loosen the nuts
to remove arm rest and arm rest guide plate.
6) Remove the hook at bottom of seat backrest.
7) Open the zipper behind backrest.
8) Remove the hog rings (A) at side of inside back-
rest from backrest frame. (Side airbag equipped
seat)
SE-00042
SE-00044
SE-00058
(A)
SE-00051
SE-00262
SE-00246
(A)
(A)
