Subaru Forester 2004 - Page 388

SE-8
SEAT
Front Seat
9) Remove the hog rings (A) which secure the
backrest cover and backrest pad.
10) Remove the headrest bushes.
NOTE:
Push the headrest bushes to outside of seat from
inside, and then remove them.
11) Pull out the backrest frame.
12) Remove the hog rings (A) at bottom of seat
back.
13) Remove the hog rings (A) at front of seat back,
and then remove the seat back cover from seat
back.
14) Remove the connecting wire (A), and then
loosen the bolts and nuts to remove slide rail.
15) Remove the inner belt.
16) Remove the hook (A), and then remove the
seat cushion frame.
SE-00242
(A)
SE-00243
SE-00244
(A)
SE-00378
(A)
SE-00295
(A)
SE-00297
SE-00268
(A)
