SL-11
SECURITY AND LOCK
Door Lock Control System
4. CHECK DOOR LOCK SWITCH AND CIRCUIT
Step Check Yes No
1 CHECK DOOR LOCK SWITCH CIRCUIT.
1) Disconnect the keyless entry control mod-
ule or double lock module harness connector.
2) Measure the resistance between the har-
ness connector terminal and chassis ground
when moving the door lock switch to LOCK.
Connector & terminal
Without double lock:
(B176) No. 10 — Chassis ground:
With double lock:
(B325) No. 7 — Chassis ground:
Is the resistance less than 10
Ω?
Go to step 2. Go to step 3.
2 CHECK DOOR LOCK SWITCH CIRCUIT.
Measure the resistance between the harness
connector terminal and chassis ground when
the door lock switch is moved to UNLOCK.
Connector & terminal
Without double lock:
(B176) No. 8 — Chassis ground:
With double lock:
(B325) No. 4 — Chassis ground:
Is the resistance less than 10
Ω?
The door lock
switch is OK.
Go to step 3.
3 CHECK DOOR LOCK SWITCH.
1) Disconnect the door lock switch harness
connector.
2) Measure the resistance between the door
lock switch terminals when moving the door
lock switch to LOCK.
Connector & terminal
LHD model:
(D7) No. 5 — No. 9
RHD model:
(D7) No. 15 — Switch ground:
Is the resistance less than 1
Ω?
Go to step 4. Replace the door
lock switch.
4 CHECK DOOR LOCK SWITCH.
Measure the resistance between the door lock
switch terminals when moving the door lock
switch to UNLOCK.
Connector & terminal
LHD model:
(D7) No. 5 — No. 8
RHD model:
(D7) No. 16 — Switch ground:
Is the resistance less than 1
Ω?
Check the harness
for open circuits or
shorts between
the keyless entry
control module or
double lock mod-
ule and the door
lock switch.
Replace the door
lock switch.
