Weighting filters for the 1/1 Octave and 1/3 Octave
analysis: A, B, C, Z for sound analysis with Audio band,
HP for vibration analysis with Full band and HPE for
sound and vibration analysis with Ultra band.
Type of integration of RMS based results for 1/1 Octave
and 1/3 Octave analysis: Linear, Fast or Slow for sound
measurements and Linear for vibration measurements.
Screen that enables setting the FFT spectrum
parameters: Band, Filter, Screen, Lines and Averaging.
Frequency band in which the FFT analysis is performed:
20 kHz, 10 kHz, 5 kHz, 2.5 kHz, 1.25 kHz, 625 Hz,
312 Hz, 156 Hz and 78 Hz.
Weighting filters used during the FFT analysis: A, C, B, Z
in the sound mode and HP in the vibration mode.
Weighting window for the FFT analysis: Hanning,
Rectangle, Flat Top or Kaiser-Bessel.
Number of lines in the FFT spectrum: 1600, 800 or 400.
Averaging used in the FFT analysis: Linear or
Exponential.
Time constant used in the exponential averaging of FFT
spectra.
