Attention
The numbers indicated in the block diagram don’t necessarily need to coincide with the Digital I/O
ports of the drive. Especially when SOMANET Circulo is used, it is important to consider that port 4 is
Digital Output only!
General Specifications
Nominal operating voltage 24 V DC (-15 %/+20 %)
Electrical isolation 500 V (field potential)
Conductor types solid wire, stranded wire and ferrule
Weight < 10g
Dimensions (LxWxH)
32mm (47mm
[1]
) x 18mm x 12mm
Operating temperature -25…+60 °C
Storage temperature -40…+85 °C
Digital Inputs 24V
Number of inputs 2
“0” input signal voltage -3…+5 V (Type 1/3 according to EN 61131-2)
“1” input signal voltage 11…30 V (Type 3 according to EN 61131-2)
Input current typ. 3 mA (Type 3 according to EN 61131-2)
Digital Outputs 24V
Number of outputs 2
Output load type ohmic, inductive, lamp load
Output current 0.35 A (short-circuit-proof) per channel
Output short circuit current typ. < 1 A
[1]
With attached strain relief.
