Embroidery starts
70
Chapter 4
7-2-1. Frame Back
Perform setting of Frame Back.(→p.146)
The setting of the machine will become Frame Back automatically at thread breakage.
(1) You want to return the frame for 1 stitch.
(2) You want to return the frame for several (2 to 10) stitches.
When performing this operation, do not put your hands etc. on the machine table. Moving
frame could injure you.
TFMX-C, TWMX-C,
TFMX-IIC TYPE-2
Press the stop switch once.
TFMX (L) Move the bar switch to the left, and return it immediately.
TFMX-C, TWMX-C,
TFMX-IIC TYPE-2
Keep on pressing the stop switch.
The frame will return stitch by stitch up to 10 stitches.
To stop, release stop switch.
TFMX (L)
Move the bar switch to the left and hold it in that position.
The frame will return stitch by stitch up to 10 stitches.
To stop, return it to the original position.
Current frame position
Embroidery direction →
The frame will return.
Current frame position
Embroidery direction →
The frame will return.
