To trim thread
82
Chapter 5
[h] Coming-out amount of hook (thread holder) (2 in the right figure)
Select B.
A: Short
B: Long
2-2-2. How to operate
The following is an example that the thread is trimmed automatically, the thread trim length is set to "+2" and
inching after ATH is set to "3".
(1) To open screen
(2) To trim thread automatically
(3) To select thread trim length
When "N" is displayed, changing "N" to a value will set the detecting sensitivity in all needle bars to the
same.
(4) To select number of inching times at start after ATH
Select “B” for hook. Wrong selection would cause abnormal noise and/or not to hold the
thread normally.
