Takeuchi TL150 Workshop Manual

IV-122
HYDRAULIC UNITS
TRAVEL MOTOR
4MAA20Z
4MAA21Z
2. Remove the plugs (23).
3. Remove the ring nut (8).
• Use the jig (C).
4. Remove the housing (1) from the flange holder.
• Use the jig (D).
5. Remove the floating seal (18) from the housing
(1) of the flange holder.

Takeuchi TL150 Specifications

General

Travel Speed - High	11.2 mph (18 km/h)
Max Travel Speed	12.4 km/h
Width	1880 mm
Height	2320 mm
Lift Height	10.5 ft (3.2 m)
