Takeuchi TL150 Workshop Manual

IV-129
HYDRAULIC UNITS
TRAVEL MOTOR
20. Mount the spring guide (46) and the spring (49)
to the spool (45), and then install it.
• Be sure to mount the spring guide (46) in the
correct direction.
21. Install the plugs (47).
Plug: 35 N·m
22. Install the relief valve (50).
Relief valve: 80 N·m

Takeuchi TL150 Specifications

General

Travel Speed - High	11.2 mph (18 km/h)
Max Travel Speed	12.4 km/h
Width	1880 mm
Height	2320 mm
Lift Height	10.5 ft (3.2 m)
