IV-132
HYDRAULIC UNITSTRAVEL MOTOR
11. Install the cover and fit the bolts.
Apply either Loctite #515 or ThreeBond #1215
to the cover surface on which the housing is
mounted.
Bolt: 16 N·m
12. Add the gear oil through the plug hole, and at-
tach the plug(24).
• Be sure to wrap seal tape around the plug.
• Gear oil to be added: 2.2 L
Plug: 22 N·m

Takeuchi TL150 Specifications

General

Travel Speed - High	11.2 mph (18 km/h)
Max Travel Speed	12.4 km/h
Width	1880 mm
Height	2320 mm
Lift Height	10.5 ft (3.2 m)
