RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 6.22
Error
code
Error Description Possible solution
11 11/OLm
Motor overload caused by a DC current
exceeding, for the maximum allowed
time (I2t), the maximum permissible
threshold for the motor in question.
-
12 12/OLr
Braking resistor overload.
• Check the resistor=150 Ω;
• low kit Driver.
19 19/EM
EMERGENCY. Is generated when low
kit drive receives a software emergency
signal that is not accompanied by a
hardware emergency signal
-
20 20/SFAn
LOW KIT DRIVER COVER PLATE
FAN. This error is generated if there is a
malfunction on the fan mounted on the
driver’s cover plate, for at least 5 sec.
• low kit driver cover plate fan.
21 21/PFAn
LOW KIT DRIVER INTERNAL FAN.
This error is generated if there is a
malfunction on the internal low kit driver
fan, for at least 5 sec
• low kit driver internal fan.
22 22/IMV
INVERTER POWER SUPPLY: This
error is generated if a voltage <156 VAC
for at least 1 sec. when the AC motor is
working or for at least 10 sec. when AC
motor is not working.
-
23 23/SHC
SHORT CIRCUIT. Is generated in the
event of a short circuit between a motor
phase and earth.
• Check the belt motor.
24 24/OHS
OVERHEATING of the dissipater
sensor: This error is generated if a
malfunction of the dissipater sensor last
more than 1 sec.
• low kit driver;
• (*).
Note (*): In case of errors related to high current consumption (such as E01), we
recommend performing a test that consists of walking on the treadmill at a pre-
established speed and checking the current consumption, according to the table below.
USER WEIGHT
FREQUENCY/SPEED
CURRENT DRAW
60Kg
1500Hz / 5Km/h
5A
70Kg
1500Hz / 5Km/h
5.3A
80Kg
1500Hz / 5Km/h
5.6A
On models not equipped with an encoder, in which the speed readout is always "0", use the
frequency value given in the table as a reference.
