Technogym RUN NOW EXCITE + - Ipod Docking Station (H)

RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 7.14
7.2.2.9. iPod Docking Station (H)
Figure 7-24
1. Lift the Docking Station covering cap up and
back off the screw (a)
using a medium
Phillips screwdriver..
Figure 7-25
2. Unplug the cable highlighted
in the figure at
the side and remove the iPod Docking
Station (H).
To reassembly the iPod docking station, follows
the above steps in the reverse order..
