Technogym RUN NOW EXCITE + - 6.13. Tread Belt Motor is Jerking

RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 6.27
6.13. TREAD BELT MOTOR IS JERKING
The probable cause is a disconnected phase either at the Driver board output or on the motor;
TREAD BELT
MOTOR IS
JERKING
Are the tread belt motor
windings resistance correct?
NO
1
YES
Replace the tread
belt motor
Replace the Driv er
Check if the IPA409
parameter is correctly
2
Follow the procedure step by step to correctly diagnose the problem. Take particular care with the
checks highlighted by circled numbers, which are described in detail below:
(1) Check parameter IPA409 as detailed in the table at the paragraph: 9.5.3. “Inverter”.
(2) Disconnect the cable from the motor and place a tester across its terminals U-V, U-W and V-
W. The measured value of the resistance should be 1.9 Ohm.
