Technogym RUN NOW EXCITE + - Visio;Visioweb Display; CPU Board: 700 Visio Models

RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 3.2
3.2. VISIO/VISIOWEB DISPLAY
Wiring Diagram refer to Chapter 2.
3.2.1. CPU BOARD: 700VISIO MODELS
The Circuit Board includes: a microprocessor, its control logic, a first FLASH EPROM (containing
the Operating System), a second FLASH EPROM, partitioned in two sections (HD1 and HD2) the
first used for the training program of the machine, for storing video and other information/support
material, the second partition for saving messages coming from the COMMUNICATOR and a third
FLASH EPROM (HD3) used for a back-up process.
It is the Circuit Board that connects all components of the display and acts as point of connection to
the driver.
The main functions of the board are:
• Manages and process signals from:
 LCD;
 LCD Inverter;
 Touch Screen;
 Digital /Analogue tuner Board;
 LAN network board (integrated);
 Wireless network Board;
 Emergency button;
 HS/HR Cardio Receiver;
 Audio/Video external device Connectors Board;
 Headphone Jack;
 C-Safe (integrated);
 Service USB port (integrated).
Optional:
 Dual TGS Reader;
 User USB port;
 iPod docking station.
• Distributes the voltages received from the low kit driver;
• Exchanges, over the RS-485 serial link to the driver box, commands for controlling the belt
and elevation motors;
• Exchanges, over the RS-485 serial link to the driver box, commands for controlling emergency
signals;
• Controls the LEDs and the 7-segment displays which provide feedback about the exercise session.
The board includes the following indicator LED:
LED mane
Colour
Description
LED 1
GREEN
if ON, the +12 Vdc power supply from the Driver correctly
reaches the board.
