RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 8.6
8.5. THE MACHINE IS NOT FLAT
This problem may be due to the positioning of the machines on a not flat surface.
To level the machine, you may adjust the height of the levelling foot.
Figure 8-4
For the levelling adjustment, carry out the operation on the rear RIGHT foot, as shown in figure:
1. Screw or unscrew the foot (a) to bring the frame in a flat and stable position.
2. At adjustment made, lock down the nut (b).
