2.10. CABLES
The colour of the cables can be changed, refer in particular to the Pin Out.
2.10.1. CBQ CABLES
CBQ32: TGS cable
(Patch conn. – CPU / ARM Board)
ARM
Board
CN4
CPU
Board
CN19
Signal Colour Patch Conn.
1
+12Vdc power supply
Red
8
3
RX
Brown
1
5
TX
Blue
2
9
GND
Black
6
2.10.2. AUTOTRANSFORMER CABLE
AUTOTRANSFORMER cable
(Autotransformer – Power supply box – ALE Driver)
Autotransformer Signal
Power
Supply
box
ALE
Driver: J1
Cable internally
connected
(PHASE) 110Vac Power Supply
1
(NEUTRAL) 110Vac Power Supply
2
(PHASE) 220Vac Power Supply
1
(NEUTRAL) 220Vac Power Supply
2
