7.20. DISASSEMBLING THE EXTRA POWER SUPPLY
Figure 7-78
Turn off the machine and unplug the mains lead
from the wall outlet.
Carry out the procedure described in paragraph:
7.14.1. “Disassembling the upper guard”.
1. Unplug the connector highlighted
in the
figure.
2. Cut the 2 cable tie (a).
3. Remove the Power Supply (b).
It’s necessary to put the cable tie (a)
again, during the reassembly.
If you
don’t have a new one do not cut it but
remove using a small flat screwdriver to
open the engaging tooth.
To reassemble the Extra Power Supply, carry out
the above steps in reverse order.
