7.10. DISASSEMBLING THE INMOTION – (READY TO RUN)
BOARD
Figure 7-47
Carry out the procedure described in paragraph:
7.9. “Disassembling the lateral handlebar”.
1. Press on the tabs (a) of the InMotion front
guard (b) and remove it from the handlebar.
Figure 7-48
2. Back off the 2 screws (c)
using a medium
Phillips screwdriver.
3. Remove the light convector (d).
Figure 7-49
4. Unplug the connector (e)
and remove the
InMotion board (f).
To reassemble the InMotion Board, carry out
the above steps in reverse order
