RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 3.6
3.12. DISPLAY UNITY
Schema a Blocchi fare riferimento al capitolo 2.
3.12.1. MAIN BOARD (MIDDELBOAR)
Main board (Middleboard): this is the control board for the cardio receiver and the interface board
for all the peripheral devices. In fact, all the electrical wiring and connections of the equipment are
hooked up to this board. It also includes a microcontroller, the software of which can be updated
(middleboard update) using a USB flash drive or Asset management tools.
3.12.2. CPU MODULE
This is a module (standard Q7 format) which contains the equipment's “heart” and intelligence. It
has an eMMC memory where the operating system and the software version of the application that
can be updated by USB flash drive or asset manager reside.
3.12.3. WI-FI MODULE:
2.
4 GHz 802.11b/g/n Wi-Fi module
3.12.4. CONTROLLER TS
TS control board to which the flat cables of the TS are connected.
3.12.5. BLUETOOTH MODULE
Bluetooth v.4.0 module board, dual mode compliant (classic & low energy master mode) controls:
• Bluetooth Heart Rate Band
• Bluetooth wireless headphones
• Connection to Apple devices (iPhone 5/ iPod) and Android devices.
This module permits surfing of smartphone contents using the Touch Screen of UNITY.
