RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 8.3
8.2. CENTRING THE TREAD BELT
Figure 8.2-1
1. Start the machine at a speed of 10km/h.
2. Observe
the movement of the tread belt,
correcting any tendency to shift to the right or
left exclusively by adjusting the left tension
screw (a)
3.
Locking down this screw favours shifting of
the belt to the right and vice versa.
The treadmill realigns slowly aft
rotation: screw (or unscrew) the bolt ¼
or ½ a turn and then check the result
before turning it again.
4. Gradually increase the speed to 16km/h,
making any small adjustments that are
necessary until the tread belt is perfectly
centred.
