RUN NOW Excite +: Technical Service guide - rev. 6.2
Pagina 9.24
9.3.8.2. Config. registers
This function displays the parameter values of type b, C, D, F, P, H and S. To access this menu,
when the LED display shows:
CONFIG REGISTERS
press ENTER, the following message appears:
ADDRESS: X
where X is the address identifying anAT UL driver parameter, as detailed in the tables at the end of
the paragraph.
Press ENTER to change the address and select a different parameter, or press + to read the value of
the currently selected parameter, the following message will appear:
READ FROM LOW KIT ?
press ENTER to load the parameter value, the following message will appear:
VALUE: Y
press ENTER to begin editing the parameter value. When finished, press + and the following
message will appear:
WRITE TO LOW KIT ?
press ENTER to confirm writing the changes to the low kit; at the end of this operation the
following message reappears:
ADDRESS: X
Although the changes made to the parameters come into effect immediately, they are not
automatically stored in permanent memory; this requires a specific write operation
effected using the command C-0: at address 800 write the value “1”, following the
detailed instructions provided in paragraph 9.3.8.2 “Config. registers”.
To return to the upper menu level press CLEAR for a few seconds.
The inverter parameters are listed at paragraph: 9.5.3. “Inverter”.
