RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 6.29
"GRADIENT NOT
WORKING" MESSAGE
ON THE DISPLAY
Check the P09
parameter is
correctly set
1
2
Replace the
limit switch
NO
NO
Set P09 = 0,
turn of f and on the machine.
The elev ation changes
(elev ation enabled)?
YES
Is the limit switch
working properly?
YES
Check that during the
movement, the pulse signals
are present on the J7
connector of the Driv er.
Replace the Driv er
and set again the
P09 = 15
NO
Check if the tension reaches
the elev ation motor during the
reset procedure
NO
Replace the elev ation
motor and set again
the P09 = 15
YES
Replace the Driv er
and set the P09 = 15
NO
4
