RUN NOW Excite +: Technical Service guide - rev. 6.2
Pagina 9.33
MENU –I–
Par.
Address
Description
Value
Par.
Address
Description
Value
I-0
100
Dig input 1 cfg
1
I-313
140
An out 2 filter
0
I-1
101
Dig input 2 cfg
0
I-350
141
Exp an out 1 cfg
0
I-2
102
Dig input 3 cfg
0
I-351
142
Exp AnOut 1 offs
0
I-3
103
Dig input 4 cfg
0
I-352
143
Exp AnOut 1 gain
100
I-4
104
Dig input 5 cfg
0
I-353
144
Exp AnOut 1 filt
0
I-5
105
Dig input 6 cfg
0
I-400
145
Inp by serial en
0
I-6
106
Dig input 7 cfg
0
I-410
146
Exp in by ser en
0
I-7
107
Dig input 8 cfg
0
I-420
147
Out by serial en
0
I-50
108
Exp dig in 1 cfg
0
I-430
148
Exp OutBySer en
0
I-51
109
Exp dig in 2 cfg
0
I-450
149
An out by ser en
0
I-52
110
Exp dig in 3 cfg
0
I-500
150
Encoder enable
1
I-53
111
Exp dig in 4 cfg
0
I-501
151
Encoder ppr
720
I-100
112
Dig output 1 cfg
48
I-502
152
Enc channels cfg
1
I-101
113
Dig output 2 cfg
48
I-503
153
Enc spd mul fact
100
I-102
114
Dig output 3 cfg
48
I-504
154
Enc update time
0
I-103
115
Dig output 4 cfg
48
I-600
155
Serial link cfg
6
I-150
116
Exp DigOut 1 cfg
48
I-601
156
Serial link bps
4
I-151
117
Exp DigOut 2 cfg
48
I-602
157
Device address
1
I-200
118
An in 1 Type
1
I-603
158
Ser answer delay
1
I-201
119
An in 1 offset
0
I-604
159
Serial timeout
0
I-202
120
An in 1 gain
100
I-605
160
En timeout alm
1
I-203
121
An in 1 minimum
0
I-700
161
Option 1 type
0
I-204
122
An in 1 filter
1
I-701
162
Option 2 type
0
I-210
123
An in 2 Type
1
I-750
163
SBI address
3
I-211
124
An in 2 offset
0
I-751
164
CAN baudrate
0
I-212
125
An in 2 gain
100
I-752
165
SBI Profibus mod
2
I-213
126
An in 2 minimum
0
I-753
166
SBI CAN mode
0
I-214
127
An in 2 filter
1
I-760
167
SBI to Drv W 0
0
I-220
128
An in 3 Type
1
I-761
168
SBI to Drv W 1
0
I-221
129
An in 3 offset
0
I-762
169
SBI to Drv W 2
0
I-222
130
An in 3 gain
100
I-763
170
SBI to Drv W 3
0
I-223
131
An in 3 minimum
0
I-764
171
SBI to Drv W 4
0
I-224
132
An in 3 filter
1
I-765
172
SBI to Drv W 5
0
I-300
133
Analog out 1 cfg
0
I-770
173
Drv to SBI W 0
1
I-301
134
An out 1 offset
0
I-771
174
Drv to SBI W 1
2
I-302
135
An out 1 gain
100
I-772
175
Drv to SBI W 2
3
I-303
136
An out 1 filter
0
I-773
176
Drv to SBI W 3
4
I-310
137
Analog out 2 cfg
2
I-774
177
Drv to SBI W 4
5
I-311
138
An out 2 offset
0
I-775
178
Drv to SBI W 5
6
I-312
139
An out 2 gain
100
Table 9-5
