RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 2.34
CU331: iPod signal cable (VISIO only)
(CPU Board– Docking Station)
CPU Board
CN26
Signal Colour Docking Station
1
+V bus USB
Black
14
2
GND bus USB
Black
13
3
TX - RX
Black
11
4
RX – TX
Black
12
5
CTS
Black
10
6
+5Vdc
Black
9
7
GND
Black
8
8
GND
Black
7
9
Video Gnd
Black
6
10
Video signal
Black
5
11
Audio L gnd
Black
4
12
Audio L signal
Black
3
13
Audio R signal
Black
2
14
Audio R gnd
Black
1
CU333: Headphone Jack cable (VISIO only)
(CPU Board– Headphone Jack)
CPU Board
J5
Signal Colour Headphone Jack
2
Out_R
Green
4
4
Schield
Yellow
5
1
GND
Red
2
3
Out_L
Black
1
CU336: LCD Inverter Frontek cable (VISIO only)
(CPU Board – LCD Inverter)
CPU Board
CN1
Signal Colour
LCD Inverter
CN1
1
+12Vdc entry Power Supply
Black
11
2 (*)
GND
Black
1
3
ON - OFF
Black
4
4
GND
Black
3
5 (*)
+12Vdc
Black
12
6
Save - lamp
Black
2
7
n.c.
Black
-
(*) =Apply two wires on the same contact.
