RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 2.36
CU375: AUDIO / VIDEO signal cable (VISIO only)
(CPU Board –AUDIO / VIDEO Connectors Board)
CPU Board: CN27 Signal Colour
AUDIO / VIDEO
Connector Board
1
n. c.
-
1
2
In L
White
2
3
GND in L
Sheath
3
4
In R
Red
4
5
GND in R
Sheath
5
6
In VIDEO
Yellow
6
7
GND in VIDEO
Sheath
7
8
n. c.
-
8
CU376: USB / C-Safe Connectors Board cable (VISIO only)
(CPU Board – USB / C-Safe Connectors Board)
CPU Board: CN6 Signal Colour
USB / C-Safe
Connectors Board
1
Vcc
Oragne
1
2
Vcc
Oragne
2
3
USB -
White
3
4
USB +
Brown
4
5
GND Shield
Black
5
6
GND
Black
6
7
GND
Nero
7
8
Af_+bvdc_csafe
Blue
8
9
Af_+bvdc_csafe
Blue
9
10
Rxd1_in
Red
10
11
Rxd1_in
Yellow
11
12
Cts1_in
Grey
12
13
GND
Black
13
14
GND
Black
14
CU377: Emergency cable (VISIO - UNITY)
(Display Board / CV – Micro 1 (Hardware)/ Micro 2 (Software)
CPU:
CN22
ARM:
CN8
UNITY
patch
Con.
Signal Colour
Micro
1
(HW)
Micro
2
(SW)
1
Emergency _SW
White
CN02
-
2
GND_DIG
Brown
-
CN05
3
Emergency _HW
Green
CN02
-
-
GND
Black
CN03
CN04
