CU574: Headphone / Mic – iPod (UNITY)
(Display Board / Headphone –Mic - iPod)
Display
Board
Signal Colour iPod
Headphone
Mic
1
iPod power (+12Vdc)
Red
3
-
2
4
3
iPod GND
Black
5
4
6
5
iPod_rx
Brown
8
6
iPod_tx
White
7
7
iPod_cts
Yellow
10
8
iPod_rts
Green
9
9
iPod_agnd (VIDEO)
Shield
11
10
iPod_con_video (VIDEO)
White
12
15
iPod_agnd (VIDEO)
Shield
17
16
iPod_lineout R (VIDEO) White 18
17
iPod_agnd (VIDEO)
Shield
19
18
iPod_lineout L (VIDEO)
White
20
20
gnd_guaina Grey 23
21
mic_input (AUDIO)
White
-
5
22
Audio HP L (AUDIO)
Yellow
3
23
agnd_ext Black
2
24
agnd_ext (AUDIO)
Shield
4
25
antphone fn (AUDIO)
Shield
6
26
Audio HP R (AUDIO) White
1
28
hphone detect
Blue
9
