RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 3.19
LED
COLOUR
STATUS
+5V_AUX Green
ON: Internal power supply to the DRIVE is correct.
OFF: in the event of a failure.
FLASHING: NO.
Micro
Down SW
(END STOP)
Green
ON: End stop pressed.
OFF: in all other cases.
FLASHING: NO.
TACO Green
ON/OFF (steady): Up/Down motor Encoder idle
FLASHING: YES (flashes during movement of the actuator to indicated that the
Encoder works).
ALARM Red
ON: On if there is a fault.
OFF: Condition cleared + MB16 command. This command is given by the high kit in
four cases:
Power on,
Emergency reset,
Exit from the service menus,
In the ARTIS line with an on-screen button, absent in Excite.
FLASHING: NO.
OUT 3 Red
ON: Active when the actuator goes up.
OFF: At all other times.
FLASHING: NO.
OUT 2 Green
ON: Active when the actuator goes down.
OFF: At all other times.
FLASHING: NO.
400Volt
MAINS
Blue
ON: DC-Link 400V active.
OFF: DC Link not active or DRIVE not powered.
FLASHING: NO.
+24 Green
ON: the 24V used for the DC motor works.
OFF: in the event of a failure.
FLASHING: NO.
+12 Green
ON: the +12VDC power supply is correctly provided by the Driver.
OFF: in the event of a failure.
FLASHING: NO.
+5 Green
ON: the +5VDC power supply is correctly provided by the Driver
OFF in the event of a failure.
FLASHING: NO.
