Texas Instruments MSP430 Student Guide

Chapter 6 Appendix
17. Build and run your code with the new Output Mode setting.
Do they both blink at the same rate? ____________________________________________
When using the “TIMER_A_OUTPUTMODE_SET_RESET” output mode …
If a compare match (TAR = CCR2) causes the output to be SET (i.e. LED goes ON),
what causes the RESET (LED going OFF)?
______________________________________________________________________
______________________________________________________________________
You may want to experiment with a few other output mode settings. It can be fun to see them
in action.
18. When done experimenting, close the project.
Chapter 6 Appendix
MSP430 Workshop - Timers 6 - 59
